Redundant Control Instrument Air N2 Generator Skid ASME PED Standard

The Redundant Control Instrument Air N2 Generator Skid features an enhanced control system design that significantly improves operational reliability and availability. This skid-mounted system offers a 2 * 100% design configuration, providing high reliability, strong availability, wide applicability, compact footprint, and continuous automatic operation.

• Integrated platform design combines all nitrogen generation components (compressor, cooler, filter, dryer, separation device) into a single steel structure
• Pre-configured with process connection ports, control power, and communication interfaces for quick installation
• Skid-mounted configuration enables easy relocation and enhanced mobility
• Modular design simplifies maintenance and component replacement

The system operates through three key processes:

1. Instrument Air Production: Air is compressed and cooled, then filtered to remove particulates and moisture
2. Nitrogen Generation: Molecular sieves or membrane separation technology separates nitrogen from other air components
3. Storage: Produced nitrogen is stored in dedicated tanks for on-demand use

• High integration: Compact footprint with optimized space utilization
• Simplified installation: Factory-assembled components reduce on-site work
• Reliable operation: Advanced technology and premium materials ensure consistent performance
• Flexible deployment: Skid-mounted design facilitates relocation between work sites

• Purity: Standard 95%+, with optional configurations achieving 99.9%+ purity
• Output: Customizable pressure and flow rates to meet specific application requirements
• Dew Point: Maintains below -40℃ for moisture-free operation

This system is widely used in industries requiring high-purity nitrogen, including:

• Food processing and packaging
• Pharmaceutical manufacturing
• Electronics production
• Oil field operations (gas lifting, downhole applications)

This is a non-standard system requiring customer-provided design specifications and datasheets for proper configuration. Our engineering team will work with you to develop a solution tailored to your specific operational requirements.
