PSA Nitrogen Generator 95%-99.9995% Purity for Industrial Use

Product Details

Place of Origin: CHINA

Brand Name: GASPU

Certification: CE

Model Number: NG

Document: GASPU nitrogen generators.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: Negotiate

Packaging Details: Plywood or other type

Delivery Time: 40work days

Payment Terms: T/T

Supply Ability: 6set/month

Get Best Price

Chat now

Product Details

Product Description

Highlight:
                                                                                                                                                                                    generator onsite nitrogen generation, psa onsite nitrogen generation, high performance psa nitrogen generator


Warranty:	One Year	Usage:	Nitrogen
Condition:	New	Purity:	95%-99.9995%
Color:	Customized	Application:	Nitrogen Generating System

Warranty:	One Year
Usage:	Nitrogen
Condition:	New
Purity:	95%-99.9995%
Color:	Customized
Application:	Nitrogen Generating System

PSA Nitrogen Generator 95%-99.9995% Purity for Industrial Use

High Performance PSA Nitrogen Generator

Reduces Energy Consumption By 20%, Saves Operating Costs

Product Specifications

Attribute	Value
Warranty	One Year
Usage	Nitrogen
Condition	New
Purity	95%-99.9995%
Color	Customized
Application	Nitrogen generating system

PSA Nitrogen Generator: On-Demand High-Purity Nitrogen Solution

Product Overview

A Pressure Swing Adsorption (PSA) Nitrogen Generator is a cutting-edge industrial system designed to produce high-purity nitrogen gas directly at your facility. By utilizing ambient air as the raw material and employing advanced carbon molecular sieves (CMS), it eliminates the logistical hassles and recurring costs associated with traditional nitrogen cylinders or liquid nitrogen deliveries.

This technology delivers a continuous, reliable, and adjustable supply of nitrogen, making it indispensable for industries like food packaging, electronics manufacturing, pharmaceuticals, chemical processing, and metal heat treatment.

Key Features & Benefits

High-Efficiency Nitrogen Separation: Leverages precision-engineered Carbon Molecular Sieves (CMS) with pore sizes (0.3-0.5 nm) optimized to kinetically separate oxygen (O₂ diameter: 0.346 nm) from nitrogen (N₂ diameter: 0.364 nm). Oxygen adsorbs faster under pressure, allowing highly pure nitrogen gas (95% to 99.9995%) to pass through as the product stream. Purity is easily adjustable based on application needs.
Continuous & Reliable Operation: Features a robust dual-tower design. While one tower actively separates nitrogen from compressed air, the other undergoes automatic depressurization (regeneration) to release adsorbed gases. This seamless switching ensures an uninterrupted, 24/7 supply of nitrogen gas without production downtime.
Exceptional Energy Savings: Achieves remarkably low power consumption, typically between 0.3-0.6 kWh per Normal Cubic Meter (Nm³) of nitrogen produced. This efficiency stems from highly optimized, rapid adsorption/desorption cycles (60-120 seconds) and carefully controlled pressure swings (0.75-0.9 MPa adsorption, atmospheric desorption).
Compact, Automated & User-Friendly: Boasts a modular footprint ideal for on-site installation. Intuitive PLC control systems with touchscreen interfaces provide real-time monitoring and adjustment of critical parameters (purity, flow, pressure) and enable effortless operation with minimal manual intervention.
Low Maintenance & Longevity: Engineered for durability. High-quality CMS boasts an extended lifespan of 5-8 years under normal operating conditions. Routine maintenance primarily involves simple filter checks and replacements (air filters monthly), ensuring low operational costs and high uptime.

Advantages Over Traditional Nitrogen Sources

Cost Reduction: Slash operational expenses dramatically. Uses free ambient air, eliminating recurring costs for cylinder refills, delivery fees, and rental charges.
Unmatched Purity Control: Adjust nitrogen purity (95% - 99.9995%) precisely to match specific process requirements, ensuring optimal results and minimizing waste. Eliminates risks of contamination inherent in handling cylinders or liquid nitrogen.
Enhanced Safety: Remove significant hazards. No need for on-site storage of high-pressure gas cylinders or cryogenic liquids, eliminating risks of explosions, leaks, or handling injuries.
Sustainable Operation: Significantly reduce your environmental impact. Zero carbon emissions from production (uses air) and transportation (on-site generation). Reduces plastic and metal waste associated with disposable cylinders.

Technical Specifications Summary

Parameter	Typical Range/Capability
Nitrogen Purity	95% - 99.9995% (Adjustable)
Flow Rate Capacity	0.1 - 500 Nm³/h (Customizable)
Operating Pressure	Adsorption: 0.75-0.9 MPa Desorption: Atmospheric
Power Supply	220V / 380V, 50/60Hz
Compressed Air Req.	~1.5-2.5 Nm³/min per Nm³/h N₂
Outlet Pressure	0.1 - 0.8 MPa (Adjustable)
Dimensions (Std.)	Approx. 800×600×1200 mm

Frequently Asked Questions (FAQ)

Q: How does the PSA process actually work?

A: Compressed, clean air enters one of two CMS-filled towers under pressure. Oxygen (O₂), moisture, and CO₂ are adsorbed onto the sieve material. Nitrogen (N₂) passes through as the product gas. Once saturated, the system automatically switches air flow to the second tower. The first tower depressurizes to release (desorb) the trapped gases, regenerating the CMS for the next cycle. The towers alternate continuously.

Q: Can I adjust the nitrogen purity for different applications?

A: Absolutely. Purity is highly adjustable from 95% (standard for inerting) up to 99.9995% (required in electronics). Higher purity is achieved by reducing the nitrogen flow rate, allowing more contact time for O₂ adsorption. Lower purity yields higher flow rates.

Q: What maintenance is involved?

A: Maintenance is straightforward: Daily pressure checks, monthly air filter replacements, and annual inspections of valves and CMS condition. The CMS itself typically lasts 5-8 years before needing replacement, depending on inlet air quality and usage intensity.

Q: Is PSA suitable for both small labs and large factories?

A: Yes. Compact generators (0.1-5 Nm³/h) serve labs, food packagers, and small electronics shops perfectly. Larger-scale industrial systems (up to 500 Nm³/h) meet the high demands of chemical plants, heat treatment facilities, and oil & gas operations.

Q: What do I need for installation?

A: Essential requirements are a stable, clean, dry environment (5-40°C), a reliable source of oil-free compressed air (filtered to ISO 8573 standards), and the appropriate electrical connection (220V/380V).

Why Choose Our PSA Nitrogen Generator?

Unrivaled Expertise & Support: Benefit from our global 24/7 technical support network for peace of mind.
Tailored Solutions: We customize purity levels, flow rates, and outlet pressure to perfectly match your unique process requirements.
Superior Efficiency: Our optimized design and cycle control reduce electricity consumption by up to 30% compared to standard generators, maximizing your ROI.

Generate Your Own Nitrogen On-Site, Safely and Cost-Effectively! Contact us today for a detailed consultation or to request a free nitrogen purity test demonstration.
